Luminescence – or the emission of light from a substance that has not been physically heated – is commonly used in science to provide visualization of entities that are not normally visible to the human eye. Chemical reactions can be used to create luminescence without the use of external light sources in techniques such as bioluminescence and chemiluminescence. Other forms of luminescence, however, require external light to trigger a glow within a substance. These latter forms of luminescence are referred to as photoluminescence and include fluorescence and phosphorescence.

Below is a brief overview of these techniques and how they are applied in life sciences research.

Bioluminescence

Bioluminescence refers to the powerful ability to see what is going on inside of organisms through the emission of visible light.¹ The technique enables researchers to study biological processes in real-time, in vivo. It has been developed over the past few decades and used primarily in small animals for the purposes of molecular imaging.

Bioluminescence works by detecting visible light that is produced when an enzyme oxidizes a molecular substrate. Most often, the enzyme, which is referred to as a bioluminescent reporter, is firefly luciferase.² However, luciferases cloned from other species have also been deemed useful. These luciferases come from organisms including jellyfish, coral, beetle, and bacteria.³ Renilla luciferase reporter gene is another commonly used enzyme in bioluminescence.⁴

Given that mammalian tissue has no intrinsic bioluminescence, images generated with bioluminescence have a high signal-to-noise ratio, and the technique can be used to visualize activity within internal organs.¹ Though the specific sensitivity of bioluminescence imaging depends on several factors, such as the depths of the labeled cells, the sensitivity of the detection system, and the level of luciferase expression, advances in the detector technology have improved sensitivity and resulting quality of images.⁵

There are a wide range of research applications for bioluminescence, including monitoring basic activity like protein interactions and intracellular motility, as well as monitoring more clinically-relevant processes like infection progression, tumor growth and metastasis, transgene expression, and the impact of gene therapy.^1,6–8  One of the most prominent reporter gene assays used in pharmaceutical development – the luminescent reporter gene assay – employs bioluminescence because this technique is conducive to relevant high-throughput screening processes.⁹

Chemiluminescence

Like bioluminescence, chemiluminescence is a highly sensitive photo emission detection method that has the advantage of not requiring an external source of light and therefore avoids the challenges associated with photobleaching, light scattering, and auto-luminescence.¹⁰  As with bioluminescence, this feature of chemiluminescence is conducive to higher signal-to-noise ratios than other luminescence methods, making chemiluminescence a well-established technique with many applications.

With chemiluminescence, light is detected due to a reaction of a substrate with a reactive oxygen species. Chemiluminescence often leverages the process by which horse radish peroxidase catalyzes the oxidation of luminol or oxalate esters by hydrogen peroxide, though other substrates are also employed.¹⁰

Advantages of chemiluminescence can be realized using both in vitro and in vivo applications.^11,12 For instance, the technique can help in the detection of several analytes, including proteins enzymes nucleic acid and even cells.^13,14 It can also enable real-time monitoring of physiology and pathology and is therefore useful for investigating aspects of drug delivery and tumor growth.¹⁵

Though chemiluminescence shares many of the advantages of bioluminescence, it also has some relative disadvantages. For example, unlike bioluminescence, chemiluminescence does not support the monitoring of processes occurring deep in tissues because the technique has a weak tissue penetration potential, and the visualization effects are short-lived.¹⁶

Photoluminescence

Photoluminescence requires that a molecule absorb light radiation and for its electrons to become excited. When this occurs, molecules transform from the ground state to an excited state. Because the excited state is unstable, the molecule inevitably reverts back to its ground state, dissipating energy.

Fluorescence

Fluorescence occurs due to differences in exciting and emitting wavelengths.¹⁷ After a photon of light energy is absorbed, it loses some energy and emits another photon nanoseconds later in what is referred to as the Stokes shift. The emitted photon carries less energy, and its light is therefore of a longer wavelength than the wavelength of the absorbed light.

Fluorescent objects are visible when the excited light is blocked out but the emitted light is not. This approach to luminescence provides superior contrast when compared with absorption approaches that involve staining with agents that absorb light, such as Gram stains. ¹⁸ Because fluorescent dyes often absorb light that is only slightly distinct from the background, the contrast they produce can be limited.¹⁷

Fluorescence is used in conventional lab techniques. For instance, western blot (or immunoblot) employs this technique to help quantify proteins. Flow cytometry also uses fluorophores – which can absorb and emit light within a range of wavelengths – in combination with antibodies to detect biological markers.

There is poor signal-to-noise when fluorescence is used within thicker tissue samples because the excitation light has to penetrate several other biological layers which lead to autofluorescence. Some efforts to improve the contrast between the background and entity of interest have led to fluorescence microscopy, which is now an integral piece of the microscopy used in biology research.¹⁹

Phosphorescence

Like fluorescence, phosphorescence occurs because of the difference in wavelength of absorbed and emitted photons. However, more energy is stored and emitted in phosphorescence than in standard fluorescence techniques. Consequently, phosphorescence generally involves much larger Stokes shifts and longer emission periods than standard fluorescence.

The use of phosphorescence has broadened in recent decades because of some specific advantages afforded by this technique including high sensitivity, selectivity, and time-resolved detection. In addition, while phosphorescence techniques were once restricted to solid phases or low temperatures, new approaches have recently evolved that allow for liquid state and room-temperature phosphorescence.

Takeaway

Luminescence is an important tool in life sciences research, particularly for visualizing molecules and biological processes. The best luminescence approach depends on the specific goals of the research. Navigating some of these tools’ applications can help elucidate their relative advantages and disadvantages.

Nisha Cooch, PhD

Dr. Nisha Cooch earned her PhD in Neuroscience from the University of Maryland School of Medicine. Dr. Cooch has conducted research at the National Institutes of Health (NIH) and served as an American Association for the Advancement of Science (AAAS) Science and Technology Policy Fellow. She is published in popular media outlets as well as peer-reviewed journals such as Nature Neuroscience. View All Articles by Nisha Cooch, PhD

References

1. Sadikot RT, Blackwell TS. Bioluminescence imaging. Proc Am Thorac Soc. 2005;2(6):511-512,537-540. doi:10.1513/pats.200507-067DS
2. de Wet JR, Wood K V, Helinski DR, DeLuca M. Cloning of firefly luciferase cDNA and the expression of active luciferase in Escherichia coli. Proc Natl Acad Sci U S A. 1985;82(23):7870-7873. doi:10.1073/pnas.82.23.7870
3. Hastings JW. Chemistries and colors of bioluminescent reactions: a review. Gene. 1996;173(1 Spec No):5-11. doi:10.1016/0378-1119(95)00676-1
4. Thorne N, Inglese J, Auld DS. Illuminating insights into firefly luciferase and other bioluminescent reporters used in chemical biology. Chem Biol. 2010;17(6):646-657. doi:10.1016/j.chembiol.2010.05.012
5. Wilson T, Hastings JW. Bioluminescence. Annu Rev Cell Dev Biol. 1998;14:197-230. doi:10.1146/annurev.cellbio.14.1.197
6. Tang Y, Shah K, Messerli SM, Snyder E, Breakefield X, Weissleder R. In vivo tracking of neural progenitor cell migration to glioblastomas. Hum Gene Ther. 2003;14(13):1247-1254. doi:10.1089/104303403767740786
7. Benaron DA, Contag PR, Contag CH. Imaging brain structure and function, infection and gene expression in the body using light. Philos Trans R Soc London Ser B, Biol  Sci. 1997;352(1354):755-761. doi:10.1098/rstb.1997.0059
8. de Almeida PE, van Rappard JRM, Wu JC. In vivo bioluminescence for tracking cell fate and function. Am J Physiol Heart Circ Physiol. 2011;301(3):H663-71. doi:10.1152/ajpheart.00337.2011
9. Miraglia LJ, King FJ, Damoiseaux R. Seeing the light: luminescent reporter gene assays. Comb Chem High Throughput Screen. 2011;14(8):648-657. doi:10.2174/138620711796504389
10. Yan Y, Shi P, Song W, Bi S. Chemiluminescence and Bioluminescence Imaging for Biosensing and Therapy: In Vitro and In Vivo Perspectives. Theranostics. 2019;9(14):4047-4065. doi:10.7150/thno.33228
11. Roda A, Pasini P, Guardigli M, Baraldini M, Musiani M, Mirasoli M. Bio- and chemiluminescence in bioanalysis. Fresenius J Anal Chem. 2000;366(6-7):752-759. doi:10.1007/s002160051569
12. Jansen EH, Buskens CA, van den Berg RH. A sensitive CCD image system for detection of chemiluminescent reactions. J Biolumin Chemilumin. 1989;3(2):53-57. doi:10.1002/bio.1170030204
13. Suzuki K, Nagai T. Recent progress in expanding the chemiluminescent toolbox for bioimaging. Curr Opin Biotechnol. 2017;48:135-141. doi:10.1016/j.copbio.2017.04.001
14. Hananya N, Shabat D. A Glowing Trajectory between Bio- and Chemiluminescence: From Luciferin-Based Probes to Triggerable Dioxetanes. Angew Chem Int Ed Engl. 2017;56(52):16454-16463. doi:10.1002/anie.201706969
15. Niu G, Zhu L, Ho DN, et al. Longitudinal bioluminescence imaging of the dynamics of Doxorubicin induced apoptosis. Theranostics. 2013;3(3):190-200. doi:10.7150/thno.5825
16. Pu K, Chattopadhyay N, Rao J. Recent advances of semiconducting polymer nanoparticles in in vivo molecular imaging. J Control Release. 2016;240:312-322. doi:10.1016/j.jconrel.2016.01.004
17. Lichtman JW, Conchello J-A. Fluorescence microscopy. Nat Methods. 2005;2(12):910-919. doi:10.1038/nmeth817
18. Becerra SC, Roy DC, Sanchez CJ, Christy RJ, Burmeister DM. An optimized staining technique for the detection of Gram positive and Gram negative bacteria within tissue. BMC Res Notes. 2016;9:216. doi:10.1186/s13104-016-1902-0
19. Sanderson MJ, Smith I, Parker I, Bootman MD. Fluorescence microscopy. Cold Spring Harb Protoc. 2014;2014(10):pdb.top071795. doi:10.1101/pdb.top071795
